產品參數
光源:
光束端:
10 x 60W RGBW LED
頻閃端:
96 x 3W CW LED
96 x 3W WW LED
96 x 0.5W RGB LED
白光色溫: 6,300K
光通量: 22,400 lm
LED預期壽命: 20,000小時
光學系統
縮放角度:
光束角度: 2.8°-31° (光束端)
光斑角度: 5°-46° (光束端)
控制與程序
5個按鍵
控制面板: LCD顯示屏
控制協議: DMX512, RDM
DMX 通道模式: 7種
通道模式: 17/27/99/108/168/8+100/8+160/170 通道
軟件升級: 通過 DMX 連接更新軟件
Y軸
Y軸運作角度: 202°
電氣與接口
輸入電源: 180-240V~ 50/60Hz
功率: 800 W
電源插座: 電源連接器輸入/輸出
信號輸入/輸出: 三芯或五芯卡儂頭插座, RJ45
產品尺寸：100＊29＊12/cm
單品包裝：108＊36＊18/cm
產品凈重：18.1kg
包裝標準：電源線一條、信號線一條、說明書一份，吊掛件一套
Light source:
Beam end:
10 x 60W RGBW LED
Strobe terminal:
96 x 3W CW LED
96 x 3W WW LED
96 x 0.5W RGB LED
White light color temperature: 6,300K
Light lux: 22,400 lm
LED life expectancy: 20,000 hours
Optical system
Zoom angle:
Beam angle: 2.8°-31° (beam end)
Spot angle: 5°-46° (beam end)
Control and procedures
5 keys
Control panel: LCD display
Control protocol: DMX512, RDM
DMX channel mode: 7 types
Channel mode: 17/27/99/108/168/8+100/8+160/170 channel
Software upgrade: update the software through DMX connection
Y-axis
Y-axis operation angle: 202°
Electrical and interface
Input power supply: 180-240V~ 50/60Hz
Power: 800 W
Power outlet: power connector input/output
Signal input/output: three-core or five-core cannon head socket, RJ45
